TVI/AHD/CVI/CVBS 1080P Video Amplifier

Boost HD video signals on longer cable runs

• Amplifies HD video over CO-AX up to 800 metres
• Video gain adjustment
• Solves weak video signal symptoms
• HD-TVI, CVI, AHD and Analogue compatible
• Wall mount design for easy siting next to a camera
• 12V DC (PSU required)
• Amplifies video signals up to 1000 times!
• Over long CO-AX  runs, the total cable resistance and capacitance can rise to values where they affect the video signal level and bandwidth. Whilst a standard monitor is quite forgiving and will reproduce a signal level as low as 0.7 Volt Peak-Peak, most other equipment and especially DVRs need a strong 1 Volt Peak-Peak signal level.
• If the signal level drops too low over a long cable run, this can result in a “No Signal” blue screen being inputted to a DVR or rolling, tearing, B&W or just plain dark images  on a monitor.
• It’s essential therefore on long cable runs to use a quality RG59 cable with a solid copper core to maximise your results but if your cable run is longer, say 500+ metres, a video amp like the AMP501 can be  a great problem solver by boosting the video signal up for a staggering 1200 metre run.
• The HD amp amplifies and equalizes the video signal, so by the time it gets to the DVR/monitor end it is restored to the levels it should be when a camera is connected directly next to it.
• Compatible with HD-TVI, CVI, AHD and analogue video the unit is 12V DC and has small fixing lugs making it easy to install right next to a camera and share its power supply.
• Installing next to the camera means that a pure and crisp image is being amplified rather than a signal that may have picked up a little noise or interference along the cable run itself but the Amp can be fitted at the DVR or monitor end if camera access is limited.
• 1 Year Warranty

• Video Output BNC
• Power 50mA
• Input Power 12V DC
• PSU Not included
• Dimensions 86x63x23mm
