Send 4 Video Input Signals to 16 Video Outputs

• 4 x BNC Video Inputs
• 1U Rack Mount
• PSU Supplied
• 16 x BNC Video Outputs
• Bandwidth 10Hz - 15Hz
• 12v DC, 350mA
• 1 Year Warranty

The CCT151 is a rack mounted video distributor capable of duplicating 4 video input signal to 16 outputs: each input goes up to 4 outputs.

Video distributors take video inputs and duplicate them for multiple outputs allowing them to be driven to additional equipment such as extra monitors and quads, or for running extra video signals around a building.



TECHNICAL SPECIFICATION: CCT151
No of Inputs	4
Type of Input	Video
Input Connection	BNC Socket
No of Outputs	16 (1:4 Duplication)
Type of Output	Video
Output Connection	BNC Socket
Power	12v DC
Current Consumption	350mA
Bandwidth	10-15Hz
Mount	1U Rack
Dimensions	(W)482mm x (D)104mm x (H)45mm
