8 Channel RF Modulator Supports Video & Audio

• Easy Operation
• Tuneable Output Channels 21-69
• 8 Phono Inputs
• LED Channel Display
• Push Button Controls
• Channel Memory
• 1 Year Warranty

Converts the composite video signal of a CCTV camera or other devices such as DVRs, Quads & switchers into an RF signal that can be displayed through a standard TV aerial system.

Many homes use a distributor that allows more than one TV to share the aerial so that you can watch TV in more than one room. If this is the case and you have connected the input from the modulator, all the TVs in the home will be able to watch images from the CCTV camera.This is one of the big advantages of using an R.F modulator. Now the UK is converting to digital TV this analogue modulator can be used easily without TV channel interference.

With great features the RF modulator has to offer, easy operation, excellent video and audio linearity for superior picture quality, LED display, MCU control for frequency control and accuracy. The 8 video&audio input with 1 RF output modulator is a great product.

TECHNICAL SPECIFICATION: CCT818
Input Connection	Phono Socket
Audio Inputs	8
Audio Input Connection	Phono Socket
Output Connection	RF Co-ax Socket
Output Channels	21-69
Power	100-260V AC
Frequency	470MHz-860MHz
Impedance	75 Ohms
Insertion Loss	30dB min
Mount	Rack Mount 1U
Dimensions	(D)180mm x (W)485mm x (H)44.5mm
