Passive Infrared
• Detect motion by measures infrared light radiating from moving objects
that emit heat.
• Greatly reduces false alarms compared to image-based motion detection.
• Helps to reduce unnecessary storage wastage caused by false triggers.
Local Recording
• Integrated microSD card slot allows you to record videos or take snapshots
without the need for additional backend software or storage.
• Record continuously or when motion is detected.
• Supports up to 32GB microSD card.
Specifications
Functions & Features
Features
HD 720p, 30 fps
Day and night with ICR filter and IR LED
10m night vision
Enhanced PIR motion detection
Built-in microphone and speaker
MicroSD card slot for video recording
Technical Specifications
Hardware Features
Indoor/Outdoor
Indoor only
Image Sensor
1/4” 1-Megapixel progressive scan CMOS
Maximum Video Resolution (Ratio)
1280 x 720 (16:9)
960 x 720 (other)
Maximum Frame Rate
Up to 30 fps
Lens
Fixed 1.8 mm, F2.4
Minimum Illumination (Lux)
1.0 lux/F2.4 (colour)
0.5 lux/F2.4 (B/W)
0 Lux (B&W, IR-LED on)
Infrared-Cut Removable Filter
Yes
IR Built-in
10 m
3D Noise Reduction
Yes
Angle Of View (H/V/D)
97.6° / 69.2° / 108.9°
PIR Motion Sensor
10 m
Privacy Masks
3 zones
Audio Codec
G.711
AAC
2-Way Audio
Built-in Microphone
Built-in Speaker
Wired Connection
Fast Ethernet (10BASE-T, 100BASE-TX)
Wireless Connectivity
802.11b/g/n
Digital Input/Output (DI/DO)
1/1
Onboard Storage Card Slot
MicroSD SDHC (max. 64 GB)1
Software Features
Video Format
H.264
MJPEG
Multi-Stream
Yes
ONVIF
Yes
Digital Zoom
4x
Motion Detection
Yes
Event Recording
Yes
E-Mail Notification
Yes
Recording to NAS
Yes
IPv6 Support
Yes
Others
Dimensions
95 x 58 x 30.7mm
Operating Temperature
0 ~ 40°C
Operating Humidity
20 ~ 80% RH (non-condensing)
Safety
CE (Class B)
CE LVD
FCC (Class B)
C-Tick
