SPRO 8MP HD-CVI Motorised Lens Turret With Built-In Microphone 60m IR - 3 Year Warranty

Information:

• The DHD80/ARW/60M-T-M can capture 4k footage and offer up to 60m IR with a built-in microphone to utilise the audio over co-ax. Feature with compatible recorders.
• Audio over co-ax allows the camera to transmit audio picked up from its built-in microphone and transmit this over the came co-ax cable as the video transmission. An audio over co-ax compatible recorder is required to fully utilise this function and would allow audio on each channel an audio over co-ax camera is on.
• Due to the sensitivity of these cameras you may occasionally get some interference from the power supply. We recommend that you use either a 3amp ungrounded power supply or, if using a box power supply, one of the dedicated isolators.
• 3 Year Warranty

• Model Number DHD80/ARW/60M-T-M
• Image Sensor 1/2.7 inch CMOS
• Effective Pixels 3840(H)×2160(V), 8MP
• Electronic Shutter Speed 1/3s-1/100000s
• Min. Illumination 0.03Lux/F1.7, 30IRE, 0Lux IR on
• Max. IR LEDs Length Distance up to 60m
• IR On/Off Control Auto/Manual
• IR LEDs 2

• Lens Type Motorized lens
• Mount Type φ14
• Focal Length 2.7mm–13.5mm
• Max Aperture F1.7
• Angle of View H.: 105°–33° × V.: 56°–18°× D.: 126°–38°
• Iris Type Fixed iris
• Close Focus Distance 0.8m
• DORI Distance Detect: 90-264 m
• Observe: 36-264 m
• Recognize: 18-53 m
• Identify: 9-26 m

• Pan/Tilt/Rotation Pan:0˚~360˚ / Tilt: 0° ~ 78° / Rotation: 0° ~ 360°

• Resolution 4K (3840 × 2160); 5M (2592 × 1944); 4M (2560 × 1440);
• 960H (960× 576/960 × 480)
• Video Frame Rate CVI: 4K@15fps; 5M@20fps; 4M@25fps, CVBS: PAL/NTSC
• Day/Night Auto switch by ICR
• BLC Mode BLC/HLC/DWDR
• WDR 120dB
• White Balance Auto/Manual
• Gain Control Auto/Manual
• Noise Reduction 2D & 3D NR
• Smart IR Yes
• Electronic Defog Yes
• Digital Zoom 4X
• Mirror Off/On
• Privacy Masking Off/On (8 Area, Rectangle)

• Audio Port One channel, built-in mic (-A)
• Video Port Video output: HDCVI

• Power Supply DC12V±30%
• Power Consumption Max 7.8W (12V DC, IR on)
• Operating Conditions -30°C ~ +60°C / Less than 95% RH
• Strorage Conditions -30°C ~ +60°C / Less than 95% RH
• Protection Grade IP67
• Casing Metal throughout the whole casing
• Dimensions Φ122.0mm×104.8mm (Φ4.80"×4.13")
• Net Weight 0.58kg (1.28lb)
• Gross Weight 0.73kg (1.616lb)
