Specifications: |
|
|
Model Number |
DHIPNVR128-4K |
|
Main Processor |
Intel Quad-core Processor |
|
Operating System |
Embedded LINUX |
|
Display |
|
|
Interface |
2 HDMI (1 HDMI up to 3840x2160, Different Source ), 1 VGA |
|
Resolution |
3840x2160, 1920×1080, 1280×1024, 1280×720, 1024×768 |
|
Multi-screen Display |
1st screen: 1/ 4/ 8/ 9/ 16/ 25/ 36 - 2nd screen: 1/ 4/ 8/ 9/ 16 |
|
OSD |
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
|
Video Detection and Alarm |
|
|
Trigger Events |
Recording, PTZ, Tour, Alarm Out, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips |
|
Video Detection |
Motion Detection, MD Zones: 396 (22 × 18), Video Loss and Tampering |
|
Alarm input |
16 Channel, Low Level Effective, Green Terminal Interface |
|
Relay Output |
8 Channel, NO/NC Programmable, Green Terminal Interface |
|
Tracking Trigger Event |
N/A |
|
Playback & Backup |
|
|
Sync Playback |
1/4/9/16 |
|
Search Mode |
Time/Date, Alarm, MD & Exact search (accurate to second), Smart search |
|
Playback Functions |
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom |
|
Backup Mode |
USB Device/ Network/ eSATA Device |
|
Storage |
|
|
Internal HDD |
8 SATA III Ports, up to 8TB capacity for each HDD |
|
HDD Mode |
Single, Raid 0/ 1/ 5/ 6/ 10/ 50/ 60 (Support Global HDD Hot-spare) |
|
eSATA |
1 eSATA port |
|
Auxiliary Interface |
|
|
Front Cover |
Support Hot-swap |
|
USB |
4 ports (2 Rear USB3.0, 2 Front USB2.0) |
|
RS232 |
1 Port, for PC Communication and Keyboard |
|
RS485 |
1 Port, for PTZ Control |
|
Third-party Support |
|
|
Third-party Support |
Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, and more. |
|
Audio and Video |
|
|
IP Camera Input |
128 channel |
|
Two-way Talk |
1 Channel Input, 1 Channel Output, RCA |
|
Intelligence |
|
|
Intelligent Functions |
Tripwire, Intrusion, Face detection, Smart tracking, People counting |
|
Recording |
|
|
Compression |
H.265/ H.264/ MJPEG |
|
Resolution |
12Mp/ 8Mp/ 6Mp/ 5Mp/ 4Mp/ 3Mp/ 1080P/ 720P/ D1&etc. |
|
Record Rate |
384Mbps |
|
Bit Rate |
16Kbps ~ 20Mbps Per Channel |
|
Record Mode |
Manual, Schedule (Regular (Continuous), MD, Alarm), Stop |
|
Record Interval |
1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
|
Network |
|
|
Interface |
2 RJ-45 port (10/ 100/ 1000Mbps) |
|
Ethernet Port |
2 Ethernet Ports Joint Working or 2 Independent 1000Mbps Ethernet Ports |
|
PoE |
N/A |
|
Network Functions |
HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, Alarm Server, IP Search, P2P |
|
Max. User Access |
128 users |
|
Smart Phone |
iPhone, iPad & Android |
|
Interoperability |
ONVIF 2.4, CGI Conformant |
|
Electrical |
|
|
Power Supply |
Single, AC 100~240V, 50/60 Hz |
|
Power Consumption |
NVR: <20W (without HDD) |
|
Environmental |
|
|
Operating Conditions |
-10°C ~ +55°C (+14°F ~ +131°F), 86 ~ 106kpa |
|
Storage Conditions |
-20°C ~ +70°C (-4°F ~ +158°F), 0 ~ 90% RH |
|
Construction |
|
|
Dimensions |
2U, 440mm x 451.5mm x 95mm ; (17.3" x 17.8" x 3.7") |
|
Net Weight |
9kg (19.8 lb) (without HDD) |
|
Gross Weight |
10.5kg (23.1 lb) |
|
Installation |
Rack-mounted |
