No need to worry about compatibility issues or future upgrades! The Scatterbox range of Video Distributors feature Quad technology for compatibility with HD-TVI, HD-CVI, AHD and standard analogue!
Video distributors take video inputs and duplicate them for multiple outputs allowing them to be driven to additional equipment such as extra monitors and quads, or for running extra video signals around a building.
They are popular in commercial and retail installs where a variety of viewing screen combinations are required.
These distributors are great for long cable runs as they can send each signal over 200M without interference.
Choose a model to suit your installation:
Code: DIST0104 1 IN - 4 OUT Desk Mount, 1:4 duplication >>THIS MODEL<<
Code: DIST0116 1 IN - 16 OUT Rack Mount, 1:16 duplication
Code: DIST0408 4 IN - 8 OUT Desk Mount, 1:2 duplication
Code: DIST0824 8 IN - 24 OUT Desk Mount, 1:3 duplication
Code: DIST1664 16 IN - 64 OUT Rack Mount, 1:4 duplication
FEATURES
-
Compatible with analogue, AHD,TVI & CVI
-
1 Inputs / 4 Outputs
-
12V DC PSU Supplied
-
Desk Mount
-
Quad Technology
-
HD 1080P Compatible
-
BNC Connections
-
Long Cable Runs
SPECS
-
No of Inputs 1
-
Type of Input Video
-
Input Connection BNC Socket
-
No of Outputs 4
-
Type of Output Video
-
Output Connection BNC Socket
-
Power 12V DC
-
Current Consumption 130mA
-
PSU Supplied
-
Bandwidth 36MHz
-
Mount Desktop
-
Dimensions 27mm x 143mm x 113mm
