Ultra-thin device body with ultra-thin border for 3 sides.
-
2 channels of 8 bit/10 bit LVDS HD (1920 × 1080) display.
-
178° ultra-wide view screen.
-
3D noise reduction.
-
Built-in speaker for audio input.
-
Support 1 channel BNC surveillance video input with professional surveillance standard BNC interface.
-
Multimedia playing of text, image, audio, video, etc.
-
Support VESA wall mount
-
3 Year Warranty
Display
Screen Size21.5”
Active Display Area478.656 (H) mm × 260.28 (V) mm
Resolution1920 × 1080
BacklightE-LED
Pixel Pitch0.0831 (H) mm × 0.241 (V) mm
Brightness250 cd/㎡
Viewing Angle178°/178°
Color Depth8 bit
Contrast Ratio3000:1
Response Time6.5 ms
Refresh Rate60 Hz
Haze
Reliability7 × 18H
Color Gamut72%
Interface
Video & Audio InputHDMI 1.4 × 1, VGA × 1，CVBS × 1，AUDIO IN × 1
Video & Audio OutputSpeaker（2W 8Ω）× 2
Power
Power Supply100 to 240 VAC, 50/60 Hz
Power Consumption≤ 22 W
Standby Consumption≤ 0.5 W
Working Environment
Working Temperature0 ℃ to 40 ℃ (32 ℉ to 104 ℉)
Working Humidity10% to 80% RH (non-condensing)
Storage Temperature–20 °C to 60 °C (–4 °F to 140 °F)
Storage Humidity5% to 90% RH (non-condensing)
General
Casing MaterialPlastic
VESA75 mm × 75 mm, 4-M6 × 6 screw holes
Bezel Width1.88 mm (top/left/right), 19 mm (bottom)
Product Dimensions (W × H × D)
Package Dimensions (W × H × D)647 (W) mm × 111 (H) mm × 406 (D) mm (25.49'' × 4.37'' × 15.99'')
Net Weight2.6 ± 0.5 kg (5.7 ± 1.1 lb.)
Gross Weight4.0 ± 0.5 kg (8.8 ± 1.1 lb.)
Packing ListMonitor ×1, AC power cable × 1, base bracket × 1, user manual × 1, quick start guide × 1, HDMI cable × 1
Remarks
<
