DVR365 Compact With 8 Channels

Product ID DSD228
Price: : Trade only
  • Overview
  • Description
  • Specifications
  • Recording Times
  • FAQ's
  • 8 Camera inputs
  • 4 Audio Inputs
  • Easy setup and control
  • Real time 200fps, 25fps per camera recording
  • The very latest H264 compression which with the same sized HDD records up to five times longer than JPEG DVR’s and two times longer than MPEG4-2 DVR’s
  • Up to D1 Recording
  • Built in video motion detection
  • PTZ (Pan, Tilt, Zoom) camera control
  • Privacy masking
  • Digital zoom
  • VGA Output
  • Easy backup onto USB stick supplied with this model
  • DVD writer optional
  • FREE mouse and IR remote control
  • FREE USB stick with this DVR
  • FREE Sightboss software for Remote monitoring
  • Easy local and remote backup
  • Two way Talk back funtion
  • Triplex, record, play and remote access
  • 1 Year Warranty
  • The new Compact DVR365 is a great value DVR that's packed with features:

    Easy set up and control

    The Compact is supplied with a free mouse and a remote control handset for fast installation and operation. The USB mouse makes menu navigation easy for even a first time user whilst the remote handset allows end-user control of images at the touch of a button.

    Real Time Video on all channels

    The Compact can record real-time video and 4 channels of audio from each of it's camera channels so you don't need to miss a thing.

    Remote Internet Monitoring

    This superb DVR is supplied with a free copy of SighBossTM the multi-site central monitoring station software. Normally sold for £100, find out more at www.sightboss.com.

    Network

    Using the SightBoss software supplied, this DVR can be networked so that any user in the business can monitor the CCTV images.

    PTZ support

    Despite its small price tag, the Compact is big on features. It can offer local and remote operation of most PTZ cameras on the market, it works with a massive 33 protocols!

    Talk-Back

    A built in 2-way audio channel allows a user to talk back to areas under surveillance using an external speaker or tannoy system.

    Easy local and remote back up

    Video evidence can easily be backed up locally by the user to a USB flash stick or an internal CD/DVD writer. For backing up files over the network and internet, SightBoss client software can download files for back up to a local PC's internal CD/DVD writer or hard drive.

    It's a great choice for most small CCTV camera systems. Its simple to use for any home or business owner. It provides Real Time video from all camera channels and can be accessed using the free sofware supplied on a network or over the internet.

    With a massive capacity, the unit can record all channels in real time for over a month. This can be extended much further using the scheduling, alarm event and video motion detection features that can be programmed into the DVR.

    TECHNICAL SPECIFICATION: DSD228
    Video Inputs 8
    Video in Connection BNC Socket
    Audio Inputs 4
    Audio Input Connection BNC Socket
    Video Outputs 2
    Video Out Connection BNC Socket
    Audio Output 1
    Audio Out Connection BNC Socket
    recording Speed FPS 200 FPS CIF Recording
    Max Drive Capacity 4TB
    Drive Supplied None
    Power 220v AC
    Alarm Inputs 8
    Alarm Input Connection Screw Terminals
    Alarm Outputs 6
    Alarm Output Connection Screw Terminals
    CD Backup Built-In Option Available
    USB Backup Yes
    Zoom Facility Digital Zoom
    Networkable Yes
    Network Connection RJ45
    Motion Detect 406 Zones
    Screen Display 1, 4, 8, 16
    PTZ Support Yes
    Mouse Control Yes
    VGA Output Yes
    HDD Interface SATA
    Drive Form 3.5" x 1/3H
    Dimensions W440mm x D445mm x H70mm 1U
