Hardware |
|
|
Case Size |
345 x 226 x 52mm |
|
Main Monitor Connector |
2x BNC |
|
VGA Monitor Connector |
1x D-Sub |
|
Spot Monitor |
- |
|
S-Video Monitor |
- |
|
Rack Mount |
- |
|
Video Input Connectors
|
8x BNC |
|
Alarm Input |
- |
|
Alarm Output (Relay) |
- |
|
Audio Input |
4 |
|
Audio Output |
2 |
|
Power Supply |
Internal |
|
SATA HDD Capacity |
|
|
Internal CD/DVD Combo |
No |
|
RS485 Port Connector |
2x Terminal (1x TX, 1x RX) |
RS485 Port Terminator
Switch |
2 |
|
Network Port |
Yes, 10/100 |
|
IR Remote Control Sensor |
Yes |
|
USB 2.0 Port Connector |
2 |
|
|
|
|
Display |
|
|
Display Main Monitor |
Full, 4, Sequence Full |
|
Display Spot Monitor Live |
Full, Sequence Full |
|
Display Main Monitor Playback |
Full, 4, Change with Page Button |
|
Hide Camera On Main Monitor |
Yes |
|
Hide Camera On Spot Monitor |
Yes |
|
Adjust Dwell Time On Main Monitor |
1-60 Seconds |
|
Adjust Dwell Time On Spot Monitor |
1-60 Seconds |
|
OSD Channel Name |
Up To 16 Characters |
|
OSD Time/Date |
UK & EU Format |
|
OSD Recording |
Yes Option |
|
OSD Alarm |
- |
|
OSD HDD Remaining |
Yes Option |
|
OSD Option To Display |
Channel, Time, Date, Recording, Alarm |
|
|
|
|
System |
|
|
Operating System |
Embedded Linux |
|
Compression |
H.264 |
|
Permanent Recording |
Yes |
|
Schedule Recording |
Yes |
|
Record Rate @ CIF |
200 |
|
Recording Rate @ 2-CIF |
100 |
|
Recording Rate @ D1 |
50 |
|
Playback Rate @ CIF |
200 |
|
Playback Rate @ 2-CIF |
100 |
|
Playback Rate @ D1 |
50 |
|
Resolution Settings Per Channel |
Yes |
|
Frame Rate Settings Per Channel |
Yes |
|
Frame Rate Step Up On Event |
Yes |
|
Water Mark Support |
Yes |
|
Front Keyboard Operation |
Yes, Full Control |
|
IR Remote Operation |
Yes, Full Control |
|
External Keyboard RS485 Port |
No |
|
External Keyboard Control |
No |
|
Mouse Operation |
Full Control |
|
HDD Overwrite / Alarm On Full |
Yes |
|
Motion Detection |
Yes |
|
|
|
|
Search |
|
|
Search & Playback |
By Tme & Date / Event / Log |
|
|
|
|
Event |
|
|
Number Of Events Stored |
10000 |
|
Events Logged |
No |
|
|
|
|
Buzzer Function |
|
|
Internal Alarm Sound Options |
On/Off |
|
Key Press Sound Options |
On/Off |
|
|
|
|
Backup |
|
|
USB Backup To Memory Stick |
Yes |
|
USB Backup To External HDD |
Yes |
|
USB Backup To External DVD/CD |
Yes |
|
USB Backup To Internal DVD/CD |
No |
|
Backup Audio |
Yes |
|
Auto Copy Playback Software To Backup Device |
No |
|
Easy Backup Operation |
Yes |
|
Notification Of Backup Device Capacity (Before Start) |
No |
|
Play Direct From Backup Device On PC |
No |
|
Option Backup Single Channels |
Yes |
|
Option Backup All Channels |
Yes |
|
Backup Format |
.264 |
|
|
|
|
PTZ Functions |
|
|
PTZ Support |
Yes |
|
Full PTZ Support |
Yes |
|
Support For Preset Select |
Yes |
|
Support For Preset Setup |
Yes |
|
Support For Pelco-P & Pelco-D |
Yes |
|
Support For Move To Preset On Event |
No |
|
|
|
|
Audio |
|
|
Mute Audio Out |
No |
|
Play Back Recorded Audio On DVR |
Yes |
|
Play Back Recorded Audio On Backup |
Yes |
|
|
|
|
Information Screens |
|
|
Display To Show Estimated HDD Time Using Current Settings |
Yes |
|
HDD Time Recording Display |
Shows Estimated Record Time |
|
Information Display |
HDD Size, HDD Space Remaining, Firmware Issue, Other Information |
|
Display MAC Address |
Yes |
|
|
|
|
Software |
|
|
Backup Engineer Settings To USB |
No |
|
Load Engineer Settings From USB |
No |
|
Update Firmware From USB |
Yes |
|
Factory Default |
Engineer Option |
|
Reset Passwords |
Engineer Option |
|
|
|
|
Network |
|
|
Dual Stream Network |
No |
|
Support For Mobile Phone |
Yes |
|
Support For iPhone |
Yes |
|
Support For Relay Switching |
No |
|
Support For Network Audio |
Yes |
|
Support For Network Talkback |
No |
|
Support For Network Broadcast |
No |
|
Support For Text Email On Event |
Yes |
|
Support For Email Snapshot On Event |
Yes |
|
Support For DDNS |
Yes |
|
Support For DHCP |
Yes |
|
Support For NTP Time Server |
Yes |
|
Support For Remote Settings |
Yes |
|
|
|
|
Passord Protection |
|
|
Engineer Password |
1 Password |
|
User Password |
7 Passwords |
|
Set User Password Local Access Option |
Menu, Playback, Copy, PTZ Control |
|
Set User Password Remote Access Options |
Menu, Playback, Alarm Out, Remote Talkback |
