Genie Coaxial Cabling: HD-TVI / AHD / HDCVI / CVBS Video Distributor - 16 Video Inputs to 32 Video Outputs

GCD1632HD is designed to distribute 16 x CVBS or HD Analogue video signals to 32video outputs. The GCD1632HD is built into a 19” standard 1U rack mounting cabinet. Suitable for large CCTV installations where there’s a need for multiple monitoring video feeds each input has 2 x outputs.


• 16 Video Inputs to 32 Video Outputs. (16 Sets 1 in 2 out Video Distributor)
• Support HD-TVI, AHD, HDCVI, 960H, NTSC, PAL Video Signal.
• Each Channel has One Output which Supports HD Video & Data Control Mode through the coax.
• Video Input, Output, Power Input Built in TVS Protection.
• Rack Mountable, 1U In Height.
• Power Supply Included, DC 12V 1.5A
• Power On/Off LED
• 1 Year Warranty
