2.8mm Fixed Lens
-
1/2.7" 2MP Progressive Scan CMOS
-
30fps @ 1080p
-
Detection Range: 10m
-
110° Detecting Angle
-
2D DNR, BLC, HLC, AGC
-
Dual Detection (PIR + Motion Detection)
-
12v DC Power Input
-
Size: 120 x 62 x 58mm
-
*PIR will only function when the camera is set to HD-CVI mode
-
1 Year Warranty
SPECIFICATION
Model Number: HAC-ME1200A-280-S4
CAMERA
Image Sensor: 1/2.7" CMOS
Effective Pxiels : 1920 x 1080, 2MP
Scanning System : Progressive
Electronic Shutter Speed : PAL: 1/25~1/100000s
Minimum Illumination: 0.02Lux/F2.4, 0Lux IR on
S/N Ratio: >65dB
IR Distance : N/A
IR On/Off Control: N/A
IR LEDs: N/A
LENS
Lens Type: Fixed lens / Fixed Iris
Mount Type: Board-in
Focal Length: 2.8mm
Max Aperture: F2.4
Angle Of View: H:107°
Focus Control: N/A
Close Focus Distance : 500mm
PAN / TILT /ROATATION
Pan/Tilt/Rotation: Pan:0°~360° / Tilt:0°~90° / Rotation:0°~360°
VIDEO
Resolution : 2MP
Frame Rate : 25/30fps@2MP
Video Output: 1-channel BNC HDCVI/CVBS (Can Switch)
Day/Night: Electronic
OSD Menu : Yes
BLC Mode : BLC/HLC/DWDR
WDR: DWDR
Gain Control : AGC
Noise Reduction : 2D
White Balance : Auto/Manual
Smart IR: N/A
PIR
Detection: Passive Infrared
Detection Range : 10m, 110°
Alarm Prompt: N/A
White Light Mode: N/A
Installation Height : Default Bracket, Wall mount, 2.2-3m
INTERFACE
Audio Interface: N/A
Alarms in/out: N/A
ELECTRICAL
Power Supply: 12VDC ±30%
Power Consumption: Max. 0.8W
ENVIRONMENTAL
Operating Conditions : -10°C ~ +60°C
Storage Conditions : -10°C ~ +60°C
Ingress Protection : N/A
CONSTRUCTION
Casing: Plastic
Dimensions : 120 x 62 x 58mm
Net Weight : 0.13kg
Gross Weight: 0.18kg
