KVM Switch Transmitter Unit

HDM182:

• A KVM (Keyboard, Video, and Mouse) Switch is a device that allows you to control one or more computers from a single keyboard and mouse and view them on single monitor. This is really handy when there is insufficient room for multiple monitors and keyboards, such as in a server room rack or on a small desktop or where you want to have the computer in a protected area but the monitor mouse and keyboard somewhere more accessible.
• For CCTV applications the KVM is even more useful!
• You can also use a KVM to control a DVR or NVR from a remote location. This means you can lock the NVR in say a server room, secure and out of sight but position a monitor and mouse in a reception area to control and view it. The KVM switch will even transmit IR signals allowing you to control the DVR with its IR remote control for maximum flexibility!!
• This product contains the transmitter unit only. See product code: HDM210 for full transmitter and receiver set.

Specs:

• Input Connection: HDMI
• LAN/CAT5 Connection: RJ45 Socket
• Max Cable Input: Max - 5m 1080p / 10m 720p
• Max Cable Output: 15m
• Output Connection: 1x USB
• Range: 100m Max
• Input Power Connection: 2.1mm DC Socket
• Power: 5V DC
• Current Consumption: 290mA
• PSU: Supplied
• Mount: Wallmount (Brackets Included)
• Dimensions: 163 x 80 x 19mm
