Dahua 3MP AI People Counting - Fixed Lens

Key Features

• 2.8/3.6mm Lens Available
• 1/2.8" 3MP Progressive Scan CMOS
• H.265+
• 30fps @ 3MP
• 20m IR Range
• Smart Features Incl: Tripwire, Intrusion, Abandoned/Missing
• Intelligent Features Incl: Facial Detection, People Counting
• Digital WDR
• Day/Night
• 3D DNR, BLC, HLC
• 2x Alarm In, 1x Audio Out
• 2x Alarm In, 2x Alarm Out
• ePoE
• IP67, IK10 Rated
• Size: 204 x 78 x 61mm

SPECIFICATION

• Model Number: IPC-HDW8341XP-3D-280-S2

CAMERA

• Image Sensor: 1/2.8" 3MP progressive CMOS
• Effective Pixels: 2048 x 1536
• ROM: 4GB
• RAM: 2GB
• Scanning System: Progressive
• Electronic Shutter Speed : Auto/Manual 1/3s-1/100000s
• Min. Illumination: 0.005 Lux @ F1.6
• IR Distance: 20m
• IR On/Off Control: Auto/Manual
• IR LEDs Number : 1
• Pan/Tilt/Rotation: Tilt: 0°-70°

LENS

• Lens Type: Fixed-focal
• Mount Type: M12
• Focal length: 2.8mm
• Max. Aperture: F1.6
• Angle of View: H:96° x V:70° x D:128°
• IRIS Type: Fixed
• Close Focus Distance: 0.7m
• DORI Distance : Detect:44.8m; Observe:17.9m; Recognise:9m; Identify:4.5m

SMART EVENT

• IVS (Perimeter Protection): Tripwire, Intrusion, Fast Moving, Loitering Detection, People
• Gathering, Parking Detection
• Face Detection: Face Detection; track; optimization; snapshot; report high quality picture;
• face enhancement; face exposure; face attribute extract, 6 attributes and 5 expressions:
• Gender age, glasses, expressions (Anger, Calm, Happy, Sad, Surprise) Mask, Beard; Face
• mapping setting: face, single inch photo; three snapshot methods: real-time, optimization,
• quality; face angle filter; optimization time setting
• People Counting : Support tripwire number counting; people counting in area and
• displaying and outputting yearly/monthly/weekly and daily reports. Support queue
• management and displaying and outputting yearly/monthly/weekly and daily reports.
• Support 4 tripwire rule configuration, eople counting in 4 areas and 4 queue managements
• Intelligent Search : Work together with Smart NVR to perform refine intelligent search,
• event extraction and merging to event videos

VIDEO

• Video Compression: H.265, H.264, H.264H, H.264B (sub stream also supports MJPEG)
• Smart Codec : H.264+ & H.265+
• Video Frame Rate: Main Stream: 3MP @ 25/30fps Sub Stream: D1 @ 25/30fps Third
• Stream: 2MP @ 25/30fps Fourth Stream: 2MP @ 25/30fps Fifth Stream: D1 @ 25/30fps
• Stream Capability: 5 Streams
• Resolution: 3M, 1080P, 720P, D1, CIF, VGA
• Bit Rate Control: CBR/VBR
• Video Bit Rate : H.264: 3-17664kbps H.265: 3-17664kbps
• Day/Night: Auto (ICR)/Colour/B/W
• BLC: Yes
• HLC: Yes
• WDR: DWDR
• White Balance: Auto/Natural/Street Lamp/Outdoor/Manual/Regional Custom
• Gain Control: Auto/Manual
• Noise Reduction: 3D DNR
• Motion Detection: OFF/ON
• Region of Interest : Yes
• Smart Illumination: Yes
• Defog: Yes
• Privacy Masking : 4 areas

AUDIO

• Built-in MIC: Yes
• Audio Compression: G.711a; G.711Mu; G.726; AAC; G.723
• Built-in Speaker : Yes

ALARM

• Alarm Event : No SD card; SD card full; SD card error; network disconnection; ip conflict;
• illegal access; motion detect; tampering; tripwire; intrusion; fast moving; abandoned
• object; missing object; loitering detection; people gathering; parking detection; scene
• change; audio detction; voltage detection; external alarm; face detection; people counting
• in area; stay alarm; people countingexception detection; saftey exception

NETWORK

• Network : RJ-45
• SDK and API: Yes
• Protocol : IPv4; IPv6; HTTP; HTTPs; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP;
• SFTP; DHCP;DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE;
• 802.1x; SNMP
• Interoperability: ONVIF (Profile S/Profile G/Profile T) CGI; Milestone; Genetec; P2P; RTMP
• User/Host: 20
• Storage : FTP; SFTP; Micro SD (Max. 256G), NAS
• Browser: IE9 and above, Firefox, Chrome
• Management Software : Smart PSS, DSS, NVR, IVSS
• Mobile Phone : IOS, Android

PORT

• RS-485: 1
• Audio: 2 Audio-in / 1 Audio-out (RCA port)
• Alarm : 2 Alarm-in (5mA 3V-5V DC)/ 2 Alarm-out (1000mA 30V DC/500mA 50V DC)

POWER

• Power supply: 12VDC / PoE
• Power Consumption: Max. 10.6W

ENVIRONMENT

• Operating Conditions: -40°C to +60°C
• Storage Temperature : -40°C to +60°C
• Ingress Protection: IP67; IK10

STRUCTURE

• Casing : Metal
• Dimensions: 204 x 78 x61.5mm
• Net Weight: 0.81kg
• Gross Weight : 1.19kg
