Dahua 3MP - 2.7-12MM Motorised Lens

Key Features

• 2.7-12mm Lens
• 1/3" 3Mp progressive scan CMOS
• 25/30fps @ 3Mp
• Face, Tripwire, Intrusion, Scene Detection
• Smart triple streams supported
• Ultra WDR up to 120dB
• Day/Night IR Cut
• Ultra 3D DNR, Defog, ROI, EIS, BLC, HLC
• PoE
• Micro SD card support
• Smart IR Range 30m
• 1x Audio, 2x Alarm in & 1x Audio, Alarm out
• IP66 Rated
• Size: 273.3 x 94.8 x 94.8mm

SPECIFICATION

• Model Number: IPC-HFW8301E
• Image Sensor: 1/3" CMOS
• Resolution: 3.0 Megapixel
• Effective Pixels: 2048x1536
• Scanning System: Progressive
• Electronic Shutter Speed: Auto, Manual, 1/3-1/10,000s
• Minimum Illumination: 0 Lux
• S/N Ratio: >50dB
• Analogue Video Output: 1 Channel BNC
• IR LEDs: Yes
• IR Cut: Yes
• IR LED Range: 30m
• Backlight Compensation: BLC, HLC, WDR (120dB)
• White Balance: Auto, Manual
• Gain Control: Auto, Manual
• Noise Reduction: 3DNR
• Privacy Masking: 4 Areas
• EIS: Yes
• Ultra Defog: Yes
• Lens Size: 2.7 ~ 12mm
• Max Aperature: F1.2
• Focus Control: Varifocal
• Angle of View: 91.2° ~ 31.1°
• Lens Type: Auto Iris
• Mount Type: Board Lens
• Compression: H.264, MJPEG
• Resolution: 3MP, 1080p, 1.3MP, 720P, D1, CIF
• Main Stream Frame Rate: 25fps @3MP
• Sub Stream Frame Rate: 25fps @ D1/CIF
• Bit Rate: 32k - 8192Kbps (H.264)
• Audio Support: Yes
• Audio Compression: G.711a, G.711u
• Audio Channels: 1x Input 1x Output
• Smart Detection: Tripwire, Intrusion, Scene Change, Missing/Abandoned, Audio Detect,
• Face Detect
• Intelligent Function: N/A
• Ethernet Type: RJ-45 (10/100/1000 Base-T)
• Protocols: IPv4/v6, HTTP, HTTPS, SSL,
• TCP/IP,UDP,UPnP,ICMP,IGMP,SNMP,RTSP,RTP,SMTP,NTP,DHCP,DNS,PPPOE,DDNS,FTP,IP
• Filter,QoS,Bonjour
• Onvif Compatible: Onvif, PSIA, CGI
• Maximum Users: 20 Users
• Smart Phone Support: iOS, Android, Windows Phone
• Micro SD Card Support: Yes - Up to 64GB
• Alarm Inputs: 1x Input
• Alarm Outputs: 1x Output
• POE: Yes - 802.3af
• Input Voltage: DC12v, POE
• Power Consumption: 12W
• Working Environment: -30°C - +60°C <90% Humidity
• IP Rating: IP66
• Axis Rotation: N/A
• Vandal Resistence: N/A
• Dimensions: 273.3x94.8x94.8mm
• Weight: 1.25Kg
