The Genie KB-IP485 is a black RS485 and IP camera keyboard controller with an LCD display and joystick that supports the Onvif 2.4 protocol. It’s design allows quick control of the speed dome and PTZ cameras with more ease.

Features:

• RS485 control
• Onvif compatible for IP cameras
• Supports network and analogue control modes
• Unique IP address
• Supports adding devices with keyboard offline and automatically searching for devices
• Supports up to a maximum of 255 front-end devices in the same network segment
• Integrated multi-brand network / analogue module
• Supports controlling PTZ camera functions, such as preset, focus, zoom, patrol etc.
• Supports IE browser to add and configure frontend equipment parameters
• LCD display
• Joystick

Specifications:

• Weight - 0.53 kg
• RS485 - Terminal block connector
• Compatible Protocol - Pelco-D, Peclo-P, Onvif 2.4
• Ethernet - 1x Ethernet port, IEEE 802.11b/g/n
• Protocol - Onvif 2.4
• Browser - Mainstream browsers such as IE, Firefox, Chrome, Safari, etc.
• Working Temperature - 0°C ~ 55°C / 14°F ~ 131°F
• Working Humidity - 20%~80% non-condensing
• Storage Temperature - -10°C ~ 60°C / 14°F ~ 140°F
• Storage Humidity - 0~90% non-condensing
• Power Supply - DC12V-1A
• Net Weight - 1.3 kg
