Up to 1.3 megapixel (1280 × 960) resolution
•
Standard video compression with high compression
ratio, ROI (region of interest) encoding
•
Progressive scan CMOS, capture motion video without
incised margin
•
Support dual stream, and the sub-stream for mobile
surveillance
•
High-performance and long service life infrared LED,
Approx. 10 to 30 meters IR range
•
IR cut filter with auto switch
•
PoE (Power over Ethernet)
•
Built-in Micro SD/SDHC/SDXC card slot, up to 128 GB
•
Ingress Protection level: IP66
•
Impact Protection: IEC60068-2-75 test, Eh, 20J;
EN50102, up to IK10
•
Other functions: rotate mode, alarm, mirror, reset
button, etc
•
Support intrusion detection, line crossing detection
•
Support VCA, which is compatible with NVR for the
second time of video searching and analysing
MonitoringCenter included
The client software MicroView MonitoringCenter is a
centralized video management software using a distributed
structure for surveillance device control and management.
MonitoringCenter is designed to provide access and manage
-
ment to the connected multiple devices, including DVR, NVR,
DVS, network camera and decoder. Using the client, you can
easily live view the channels, record and store files, remotely
configure the device parameters, control PTZ, get alarm infor
-
mation and respond, and display video on the TV wall.
I13D
CMOS Vandal-proof Network
Dome Camera
1.3 Megapixels
An amazing 1.3 Megapixel IP network camera at
a great price. The I13D camera is a 1.3 Megapixel
Network camera giving much sharper images than
a traditional analogue camera - at least four times
sharper! The I13D can see in total darkness up to
about 30 metres using it’s built-in infrared lights.
Just plug the camera into one of our NVRs using a
standard CAT5 computer network cable and this
will power the camera and bring the picture back
to the recorder making it so simple to install, no
separate power supply needed.
Main Features
1
•
3
Megapixel
720p
BL
C
Water Mark
IC
R
Product Specifications
Camera
Image Sensor
1/3" Progressive Scan CMOS
Min. Illumination
0.01Lux @ (F1.2, AGC ON) ,0 Lux with IR
0.028 Lux @ (F2.0, AGC ON) ,0 Lux with IR
Shutter Speed
1/3 s to 1/100,000 s
Lens
4mm@ F2.0 (2.8mm, 6mm optional)
Angle of view: 92.5°(2.8mm), 73.1°(4mm),
46°(6mm)
Lens Mount
M12
Day &Night
IR cut filter with auto switch
Digital Noise Reduction
3D DNR
Wide Dynamic Range
Digital WDR
Angle Adjustment
Pan:0° - 355°, Tilt: 0° - 65°
Compression Standard
Video Compression
H.264/ MJPEG
H.264 Type
Main Profile
Video Bit Rate
32 Kbps – 12 Mbps
Dual Stream
Yes
Max. Resolution
1280 x 960
Frame Rate
50 Hz: 25 fps (1280 × 960), 25 fps (1280 x 720)
60 Hz: 30 fps (1280 × 960), 30 fps (1280 x 720)
Image Settings
Rotate mode, Saturation, Brightness, Contrast
adjustable by client software or web browser
Backlight compensation
Yes, zone optional
ROI
Local storage: Built-in Micro SD/SDHC/SDXC
card slot, up to 128 GB.
NAS (Support NFS,SMB/CIFS)
Network
Network Storage
NVR
Alarm Trigger
Line Crossing, Intrusion Detection, Motion
detection, Dynamic analysis, Tampering alarm,
Network disconnect, IP address conflict,
Storage exception
Protocols
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS,
DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP,
SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
General
One-key reset, Flash-prevention, dual stream,
heartbeat, mirror, password protection,
privacy mask, watermark, IP address filtering,
Anonymous access
PPPoE,NTP,UPnP,SMTP,SNMP,I
GMP,802.1X,QoS,IPv6,Bonjour
(SIP optional)
Yes
Security
User Authentication, Watermark
Standard
ONVIF, PSIA, CGI, ISAPI
Interface
Communication Interface
1 RJ45 10M/100M Ethernet interface
General
Operating Conditions
-30 °C – 60 °C (-22 °F – 140 °F)
Humidity 95% or less (non-condensing)
Power Supply
12 V DC ± 10%
PoE (802.3af)
Power Consumption
Max. 5 W
Ingress Protection level
IP66
IR Range
30 meters
Impact Protection
IEC60068-2-75Eh, 20J; EN50102, up to IK10
Dimensions
Φ111 × 82 (4.4” × 3.2”)
Weight
500g (1.1 lb)
MicroView
MVID-03IR
Dimensions
Accessories
Inclined ceiling mount
MVI-A1000
Wall mount
MVA-A1001
