Provision 32 Channel 8MP NVR - 3 Year Warranty

Product ID NVR8-32800RFA(2U)-1T

Provision 32 Channel 8MP NVR - 3 Year Warranty

Price: : Trade only

+

-

« Previous | Next »

Key Features:

1 - 64TB HDD Options
Up to 8MP Recording & Playback
H.265
Up to 256Mbps Incoming Bandwidth
Advanced Analytics
DDA Advanced AI Support
1x HDMI, 1x VGA
AI Features
1x Audio In, 1x Audio Out
8x Alarm In, 4x Alarm Out
Dewarp, RAID
USB/Network Backup
Size: 430 x 455 x 97mm
3 Year Warranty

SPECIFICATION:

VIDEO:

Input : 32 ch Via Network
Output: HDMI 1: 4K, 1080P, 1280x1024 / HDMI 2 & VGA: 1080P, 1280x1024
Decoding Format: H.265 & H.264
Decoding Capabilities: 4ch: 2@8MP & 2@5MP 9/16ch@1MP 32ch@:D1
Analytics: Face Recognition, Smart Search, Tampering, Line Crossing, Sterile area, Object Counting, Item Monitoring, Growd gathering
Face Recognition rate : 180 Faces per minuite(all channels) / 5 Faces per second (Single Channel)

AUDIO:

Input : 1ch + IP camera inputs
Output: 1ch + IP camera outputs
Two-way Audio: Yes

BANDWIDTH:

Incoming: 256Mbps
Outgoing: 256Mbps

RECORDING:

Real-time Recording : 32ch@8MP Real-Time
8MP: 800fps (PAL) / 960fps (NTSC)
5MP: 800fps (PAL) / 960fps (NTSC)
4MP: 800fps (PAL) / 960fps (NTSC)
3MP: 800fps (PAL) / 960fps (NTSC)
2MP: 800fps (PAL) / 960fps (NTSC)
1.3MP and Lower: 800fps (PAL) / 960fps (NTSC)
Recording Modes: Schedule, Manual, Motion, Sensor, Analytics

PLAYBACK:

Playback Channels : Local: 16ch / Remote: 32ch
Search Mode: Smart Search / Face recognition, Time-Slice, Time, Event, File Management

BACKUP:

USB: 2 USB 2.0 Port & 1 USB 3.0 Port
DVD Backup: No
Backup Format: AVI/DAT

REMOTE APPLICATION:

Main Stream: Up to 32ch@Recording Resolution
Sub Stream: Up to Outgoing Bandwidth Capacity
Browser: Safari & IE
CMS: Yes
Mobile Application: Provision CAM2 for iOS & Android
User Access: 10 Users with Proffesional Authority Management

ALARM:

Input : 8ch + IPC inputs
Output: 4ch + IPC Outputs

STORAGE:

HDD: 8 SATA (Max.8TB each)
E-SATA: No
RAID: RAID 0/1/5/6/10

PTZ:

Connection: Network
Supported Controls: Pan, Tilt, Zoom, Preset, Cruise, Scan, Iris, Focus
RS-485: No

NETWORK:

Ethernet: 2 x 1000Mbps (RJ45)
Protocol: TCP/IP, DHCP, DDNS, NTP, SMTP, P2P, RTSP, FTP, HTTPS, 820.1x
ONVIF: Yes

POE:

Ports: N/A
Interface: N/A
Standard: N/A
Total Power: N/A
Max Power Output per channel: N/A

OTHERS:

Power Supply: AC100/240V
Power Consumptions (No HDD): 15W
Dimension: W:430 x D:445 x H:97mm
Operating Temperature: 0°C - 50°C
