Pallet 25x 250m Black RG59+2 Composite Shotgun Cables

Our best selling RG59+2 composite cable allows you to send power and a video signal down just the one cable, saving you installation time and money fitting 1 cable instead of 2!

The RG59 co-ax has a 0.7mm copper core to give maximum video quality on longer cable runs and is shielded with a glued foil sheath to protect against interference. This also prevents the problem of loose foil shorting to the centre-pin.

The two cables run in shotgun style can easily be separated to allow the power cores to be taken to a power source leaving the RG59 to be crimped for connection to a DVR, camera or monitor. The power cores are 0.15 x 24 stranded to prevent interruptions and are colour coded red 12V and black 0V to avoid any errors in connection. These power cores can also be used to run 24V AC.

This cable is supplied on a pallet of 25 x 250M rolls.
