Dahua 2MP Thermal - 3.5MM Lens

Key Features

• 256 x 192 VOx Uncooled Thermal Sensor Technology
• Athermalised Lens
• 1/2.8" 2MP Progressive Scan CMOS
• Thermal Lens: 3.5mm
• Visible Lens: 4mm
• ROI, Motion Detection, Colour Palettes
• Fire Detection
• Smart Features
• 1x Audio In, 1x Audio Out, 2x Alarm In, 2x Alarm Out
• Micro SD Card Support
• PoE+
• 12v DC Power Input
• H.265 Compression
• Requires PSU
• Size: 295 x 160mm

SPECIFICATION

• Model Number: TPC-SD2221-B3F4

THERMAL CAMERA

• Image Sensor : Uncooled VOx Microbolometer
• Effective Pixel: 256 x 192
• Pixel Size: 12mm
• Thermal Sensitivity (NETD): <50mK
• Spectral Range : 8 ~ 14mm
• Image Setting: Brightness/Sharpness/ROI/AGC/FFC/3D DNR
• Colour
• Palettes: 18(Whitehot/Blackhot/Ironrow/Icefire/Fusion/Rainbow/Globow/Iconbow1/Iconbo
• w2. etc)

THERMAL LENS

• Lens Type : Fixed/F1.0
• Focus Control : Athermalized, Focus-Free
• Focal Length : 3.5mm
• Angle View: H:50.6° V:37.8°
• Effective Distance (Human): Detect: 146m, Recognise: 38m, Identify: 19m
• Effective Distance (Vehicle): Detect: 389m, Recognise: 97m, Identify: 49m

VISIBLE CAMERA

• Image Sensor : 1/2.8" 2M CMOS
• Effective Pixels: 1920 x 1080
• Electrnic Shutter Speed : 1/1~1/30000s
• Min. Illumination: Colour:0.005Lux; B/W:0.0005Lux; 0Lux (IR on)
• IR Distance : 35m
• IR Control : Auto/Manual
• IR LEDs: 1

VISIBLE LENS

• Focal Length : 4mm
• Max Aperture: F2.0
• Angle of View : H:84° V:45°
• Close Focus Distance : 0.2m

PTZ

• Pan/Tilt Range : Pan:0~360° endless; Tilt:-15~90°
• Manual Control Speed : Pan:0.1~200°/s; Tilt:0.1~120°/s
• Preset Speed : Pan:0.1~240°/s; Tilt:0.1~200°/s
• Preset: 300
• PTZ Mode: 5 Auto Scan, 8 Tours, 5 Patterns, Auto Pan
• Power Up Action: Auto restore to previous PTZ and lens status after power failure
• Idle Motion : Activate Preset/ Scan/ Tour/ Pattern
• Protocol : DH-SD, Pelco-P/D (Auto recognition)

VIDEO

• Compression: H.265/H.264M/H.264H/H.264B/MJPEG
• Frame Rate : Main Stream: Thermal: 1280x960/1024x768/640x480/256x192 @ 25/30fps.
• Visible: 1920x1080/1280x720/704x576 @ 25/30fps.
• Bit Rate Control : Auto/Manual
• Bit Rate: CBR/VBR
• Day/Night: Auto/Colour/B/W
• BLC Mode : BLC/HLC/DWDR
• White Balance : Auto/Indoor/Outdoor/Manual
• Noise Reduction : 2D DNR/3D DNR
• Motion Detection: Off/On
• Region Of Interest : Off/On
• Defog : Off/On
• Flip : 180°
• Mirror: Off/On
• Privacy Masking : Off/On

AUDIO

• Compression: G.711a/G.711Mu/AAC/PCM

INTELLIGENCE

• IVS: Tripwire, Intrusion
• Advanced Intelligent Functions : Fire detection & Alarm, Cold/Hot spot trace,
• Human/Vehicle classfication, Smoking Detection
• Tracking Trigger Mode : Manual/Auto (Alarm Triggered)
• Tracking Trigger Event: Targeting, Tracking, Recording, Snapshot, Alarm

NETWORK

• Ethernet : RJ-45 (10/100Base-T)
• Protocol : HTTP, TCP, ARP, RTSP, RTP, UDP, RTCP, SMTP, FTP, DHCP, DNS, DDNS, PPPOE,
• IPv4/v6, SNMP, Qos, UPnP, NTP
• Interoperability: ONVIF Profile S&G, API
• Steaming Method : Unicast/Multicast
• Max. User Access : 20 Users
• Edge Storage : Micro SD (256G) Memory Status Display, NAS, LocalPC for instant recording
• Web Viewer: >IE8, Chrome, Firefox, Safari
• Management Software: Smart PSS, DSS
• Smart Phone : Android, IOS

INTERFACE

• Video Interface : 1 Port (BNC)
• Audio Interface : In/Out 1/1
• RS485: Support
• Alarm : 2/1 In/Out

ELECTRICAL

• Power Supply : DC12V ±15% / PoE+
• Power Consumption : Max 24W

ENVIRONMENTAL

• Operating Conditions : -30°C to +60°C
• Storage Consumption: -40°C to +70°C
• Relative Humidity: <95%
• Ingress Protection: IP66

CONSTRUCTION

• Casing : Metal
• Dimensions : 295 x 160mm
• Net Weight: 3.2Kg
• Gross Weight : 4.7Kg
