Specification |
Details |
|
Weight |
1.17 kg |
|
Camera Image Sensor |
1 / 1.8” CMOS |
|
Camera Image Size |
2560 × 1520 |
|
Camera Electronic Shutter |
Manual or auto; manual: 1 / 1 s ~ 1 / 100000s |
|
Camera Iris Type |
DC Iris |
|
Camera Minimum Illumination |
0.0007 lux@F1.3, AGC ON; 0 lux with IR
0.001 lux@F1.6, AGC ON; 0 lux with IR |
|
Camera Lens |
8 – 32mm section
Horizontal: 41°~15.5°
Vertical: 23°~9.5°
Diagonal: 46.5°~18° |
|
Camera Lens Mount |
Integrated |
|
Camera Recommended ANPR Distance |
7~30m |
|
Camera Wide Dynamic Range |
120dB |
|
Camera BLC |
Yes |
|
Camera HLC |
Yes |
|
Camera Digital NR |
3D DNR |
|
Camera S/N Ratio |
≥50dB |
|
Camera Angle Adjustment |
Pan: 0°~360°; Tilt:0°~90°; Rotation: 0°~360° |
|
Image Video Compression |
Main stream: H.265+ / H.265 / H.264+ / H.264
Sub stream: H.265+ / H.265 / H.264+ / H.264 / MJPEG
Third stream: H.265+ / H.265 / H.264+ / H.264 / MJPEG |
|
Image H.264 Compression Standard |
Baseline Profile / Main Profile / High Profile |
|
Image Resolution |
4MP (2592 × 1520), 2K (2560 × 1440),
3MP(2304 × 1296), 1080P(1920 × 1080),
720P (1280 × 720), D1, CIF |
|
Image Main Stream |
4MP/2K/3MP/1080P (60Hz: 1 ~ 30fps; 50Hz: 1 ~ 25fps)
HFR Mode: 1080P/720P (60Hz: 1~60fps; 50Hz: 1~50fps) |
|
Image Sub Stream |
720P/D1/CIF (60Hz: 1 ~ 30fps; 50Hz: 1 ~ 25fps) |
|
Image Third Stream |
D1/CIF (60Hz: 1 ~ 30fps; 50Hz: 1 ~ 25fps) |
|
Image Bit Rate |
64 Kbps ~ 8 Mbps |
|
Image Bit Rate Type |
VBR / CBR |
|
Image Audio Compression |
G711A / U |
|
Image Settings |
ROI, Saturation, Brightness, Hue, Contrast, Wide Dynamic, Sharpness, Image Mirror, Image Flip, NR, etc.
adjustable through client software or web browser |
|
Image ROI |
Each ROI to be configured separately |
|
Interface Network |
100M RJ 45 |
|
Interface Video Output |
CVBS output (BNC × 1) |
|
Interface Audio |
1CH audio input; 1CH audio output |
|
Interface Alarm |
1CH alarm input, 1CH alarm output |
|
Interface Storage |
Built-in Micro SD card slot, up to 256GB |
|
Interface Hardware Reset |
Yes |
|
Interface RS 485 |
Yes |
|
Interface Wiegand |
Yes |
|
Functions Remote Monitoring |
Web Browser/NVMS2.0/NVR/mobile APP |
|
Functions Web Browser |
IE11(plug-in required)/Chrome 89.0+/Edge 89.0+/Firefox 87.0+/ Safari 14.0+ |
|
Functions Online Connection |
Support simultaneous monitoring for up to 10 users; Support multi-stream real time transmission |
|
Functions Network Protocol |
UDP, IPv4, IPv6, DHCP, NTP, RTSP, RTP, RTMP, RTCP, PPPoE, DDNS,
SMTP, FTP, SNMP, HTTP, HTTP POST, 802.1x, UPnP, HTTPs, QoS |
|
Functions Interface Protocol |
Onvif compatible |
|
Functions Storage |
Network remote storage; micro SD card storage |
|
Functions Intelligent Analytics |
License plate recognition, vehicle type detection, video exception detection |
|
Functions Smart Alarm |
Motion detection, sensor alarm, SD card error, SD card full, IP address conflict, cable disconnection |
|
Functions General |
Watermark, video mask, heartbeat, corridor mode |
|
Functions Security |
Video encryption, firmware encryption, HTTPs encryption, configuration encryption,
illegal login lock, IP address filtering, 802.1x authentication, basic and
digest authentication for HTTP/ HTTPs |
|
Functions PoE |
Yes, IEEE802.3af |
|
Functions IR Distance |
70~100m |
|
Functions Protection Grade |
IP67 |
|
LPR Snapshot |
Overview and cut-out of plate for picture |
|
LPR Vehicle Plate Database |
10000 |
|
LPR Capture Speed Range |
0~120km/h |
|
LPR OSD Information Overlay |
A lot of information can be overlaid on the captured original image,
including snapshot time, location, license plate, plate colour, traffic violation information |
|
Ingress Protection |
IP67 |
|
Power Supply |
DC12V/AC24V/PoE |
|
Power Consumption |
< 12W |
|
Operating Environment |
–30 °C ~ 60 °C (-22°F~140°F);
Humidity: less than 95 % (non-condensing) |
|
Storage Environment |
–30 °C ~ 65 °C (-22°F~149°F);
Humidity: less than 95 % (non-condensing) |
|
Dimensions |
278.3 × 100.2 × 88.7 mm |
|
Weight |
Approx. 1176g |
|
Installation |
Ceiling mounting; Wall mounting |
|
Certificate |
CE, FCC |
|
Environmental Protection |
Complies with Directive
EU RoHS, WEEE(2012/19/EU), directive 94/62/EC and REACH(EC1907/2006) |
