Specification |
Details |
|
System OS |
Embedded Linux |
|
Mobile OS |
iOS, Android |
|
IP Video Input |
32 channel IPC input |
|
Incoming Video Bandwidth |
320Mbps |
|
Outgoing Video Bandwidth |
256Mbps |
|
IP Video Input Resolution |
12MP / 9MP / 8MP / 6MP / 5MP / 4MP / 3MP / 1080p / 1280 × 1024 / 960p / 720p / 960H / D1 / CIF |
|
Video Output |
HDMI1: 3840 × 2160 / 1920 × 1080 / 1280 × 1024 / 1024 × 768
HDMI2: 1920 × 1080 / 1280 × 1024 / 1024 × 768
VGA ×1: 1920 × 1080 / 1280 × 1024 / 1024 × 768
VGA and HDMI1 output the same video source |
|
Video Compression |
H.265S / H.265+ / H.265 / H.264 |
|
Multi-screen Display |
Main output: 1/4/6/8/9/13/16/25/32/36 (live view)
AUX output: 1/4/6/8/9 (live view)
Max. 32+9 Channel local live view |
|
Face Detection Performance (AI by IPC) |
32 Channel |
|
Face Detection Performance (AI by Device) |
2 Channel (2MP) |
|
Face Recognition Comparison Capability |
18 pictures / second |
|
Face Picture Database |
32 libraries, 5000 face pictures |
|
Face Picture Search |
Search by picture is supported |
|
Face Recognition Database Management |
Add, modify, delete and search face pictures |
|
Face Picture Adding |
Add face pictures through App, Web and external import |
|
Face Picture Comparison |
Support successful face recognition alarm and stranger match alarm |
|
Face Track |
Yes |
|
Statistic Graph of Face Information |
Bar graph |
|
Statistic Mode of Face Information |
Statistics by day, week, month, quarter as well as customized time period |
|
Perimeter Protection - Human/Vehicle Classification (AI by IPC) |
32 Channel |
|
Perimeter Protection - Human/Vehicle Classification (AI by Device) |
2 Channel (2MP) |
|
Network Interface |
RJ 45 1000 Mbps × 2 |
|
Network Protocol |
TCP / IP, HTTP, HTTPs, 802.1X, FTP, DHCP, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IPv6, IPv4, UDP, WebSocket, PPPoE, SNMP, IGMP |
|
Network Client Connections |
Max. 128 users access |
|
RS485 |
Yes (full-duplex), connect to PTZ or keyboard |
|
USB |
USB 3.0 × 1 ; USB 2.0 × 2 |
|
Remote Controller |
Optional |
|
Simultaneous Playback |
Max 16 Channel |
|
Playback Search |
Time slice / Time / Event / Tag / Smart search |
|
Playback Smart Search |
Highlighted color to display the camera record in a certain period of time, different colors refer to different record events. |
|
Playback Function |
Play, pause, FF, FB, digital zoom, etc. |
|
Playback Decoding Capability |
Live View / Playback: 1 Channel 12MP / 4 Channel 1080P |
|
Alarm Mode |
Manual, Sensor, Motion, Exception, Smart events |
|
Alarm Input |
16 Channel local alarm inputs |
|
Alarm Output |
4 Channels |
|
Alarm Triggering |
Record, Snap, Pre-set, E-mail, etc. |
|
Record Stream |
Dual stream recording |
|
Record Resolution |
12MP / 9MP / 8MP / 6MP / 5MP / 4MP / 3MP / 1080P / 1280 × 1024 / 960P / 720P / 960H / D1 / CIF |
|
Audio Network Input |
32 Channel IPC audio input |
|
Power Supply |
ATX 300W (PoE) |
|
Consumption |
≤ 30W (without HDD and PoE power supply) |
|
Certificate |
CE, FCC |
|
Dimensions |
445 × 436 × 90 mm |
