Brand

Xvision Pro HD

Model Number

XC1080CW

Type

Style

High Definition Cube Camera

Weather Resistant

No

Vandal Resistant

No

Motorised Panning

No

Motorised Tilting

No

Digital Zoom

No

Audio:

Yes

Mounting Type:

Wall or Ceiling

Product Dimensions WxHxD (mm):

68x129x65

Product Weight

0.50kg

Shipping Dimensions WxHxD (mm)

165x165x125

Shipping Weight

0.55kg

Warranty

1 Year Warranty (extendable to 3 years)

Camera

Image Sensor Type

1.29 Sony CMOS

Image Sensor Resolution

1.3 Mega Pixel 960P

Minimum Illumination

0.0003 Lux

Night Vision

Yes (Optional IR Lamp Required)

Other Features

Automatic White Balance
Automatic Gain Control
Automatic Electronic Iris
DNR (Digital Noise Reduction)
WDR (Wide Dynamic Range)

Lens

Not Supplied

Viewing Angle

N/A

Performance

Video Compression

H264

Video Streams

16Kbps-8000Kbps

Stream Types

Complex stream/Video stream

Video Resolution & Frame Rates

1280x960 25fps

Networking

Network Connection

RJ45 Socket (10/100 BASE-T)

Wi-Fi Support

Yes

Network Protocols Supported

TCP/IP,UDP,HTTP,DHCP,RTP/RTSP,

DNS,DDNS,NTP,PPPOE,UPNP,SMTP

Remote Access

Browser Support

Internet Explorer,

Mobile Phone Support

Android, iPhone

User Authentication

Yes

Simultaneous Viewers

10

Power Requirements

Power over Ethernet

No

Operating Voltage

12V DC

Power Consumption

<6W

Other Features

Easy Fit

Yes (Wifi)

Motion Detection

Yes

Presets

No

Guard Tours

No

Email Alerts

Yes

On Board Recording

Yes

Alarms

Yes

Multi Camera Software

Yes
