Works with 4K, TVI, CVI, AHD & CVBS
-
Colour Coded Rx (Blue) & Tx (Red) Baluns
-
Pigtail Connection for Easy Cabling
-
No Power Required
-
4K up to 130m TX
-
HD up to 250m TX
-
CVBS up to 400m TX
-
Works on CAT5, 6 & 7
-
Video -BNC Plug
-
Push Down Terminals
-
1 Year Warranty
These superb little Baluns are pocket rockets when it comes to sending HD video signals up to 4K down either CAT5 or 6 cable! We have tested them with 2MP, 5MP and 4K cameras and they perform flawlessly producing great quality images. They are sold in pairs and you put the Transmitter at the Camera end and the Receiver at the DVR end. Each Balun pair uses one pair of cores out of a CAT5/6 cable so you can send 4 cameras down a standard 4 pair cable but remember you will still need to power the camera which if you use all cores for video would mean local power for the camera.
The BAL4KPs are designed to slot together for really neat and professional installation. For example, you can slot two Baluns together to make a two camera Balun. Connecting the baluns in this way also saves time in the future as you will have an organised installation rather than a mass of wires.
Backwards compatible with old CVBS CCTV cameras these are a definite choice to keep in the tool box and with bulk discounting available a popular buy.
The BAL4KPs feature a pigtail BNC plug for easily connecting to a DVR or cameras and screw terminals for quickly connecting a twisted pair/CAT5.
Baluns contain small signal transformers that are specially tuned to match the cables impedance and convert the unbalanced signal to a balanced one in fact PASSIVE baluns just have the transformers and very little else in them.
TOP TIP - with slightly different electronics to standard baluns, they are supplied as a TX / RX pair but are handily colour coded with the red TX balun going at the camera end of your CAT5 cable.
|
BAL4K |
Compatibility |
4K / 5MP / 2MP / CVBS |
|
No of Video Inputs |
1 |
|
Video Input Connection |
BNC Plug (Male) |
|
CAT5 Output Connection |
Screw Down Terminals |
|
Max 4K Distance |
130m |
|
Max HD Distance |
250m (2MP / 5MP) |
|
Max CVBS Distance |
400m |
|
Video Bandwidth |
71 MHz |
|
Power |
Passive (Not Required) |
|
Pack Size |
1 Pair |
|
Dimensions |
(H) 21 x (W) 17 x (D) 39mm (Exc Lead) |
|
