Cable - Rg59 Co-Ax - 250M Black

CAB520:

• RG59 is a co-ax type cable ideal for bringing video signals back from cameras to other CCTV equipment such as DVRs, quads and monitors.
• It is a low loss cable losing only approximately 2.5dB of video signal over a 100 metre run. As a rule of thumb, the maximum loss should be kept under 6dB. This means a massive cable run of 240 metres can be achieved without the use of an amplifier. Using a video amplifier runs of up to 500 metres can be achieved.
• The RG59 co-ax has a 0.7mm copper core to give maximum video quality on longer cable runs and is shielded with a glued foil sheath to protect against interference. This also prevents the problem of loose foil shorting to the centre-pin.
• This cable is supplied in 250M rolls with a black sheath.

• Solid Copper Centre cores not inferior coated alternatives like CCS or CCA*
• Glued foil sheaths (not loose) to prevent shorting on the centre pin
• Supplied on wooden drums so not soggy card reels
• Quality protective sheath resists cable damage

Specs:

• Sheath Colour: Black
• RG59 Core: 0.7mm Bare Copper Conductor
• RG59 Shield: 48 x 0.12mm CCA
• RG59 Foil: Copper Coated Aluminium
• Outer Sheath: PVC
• Pallet Quantity: 55
• Cable Length: 250 Mtr Roll
• Dimensions: 250m Roll x 235mm Roll Dia
