We're really sorry... We don't currently have that one in stock Please add your email and we'll notify you when it's back Email Home» Accessories» Power Over Ethernet HDMI Over IP Extender With RS232 ReceiverProduct ID DA-HL101RPrice: £109.99 (£131.99 Inc. VAT)+- Add to cart« Previous | Next »DA-HL101R Receives HDMI signal via LAN RS-232 Control Pass-Thru to control HDMI H.264 Bit Rate 20Mbps 1x RJ-45 Connector For use with DA-HL101T DC 5V / 750mA 109 x 107.5 x 36 mm 3 Year Warranty SPECIFICATION Model Number: DA-HL101R Unit Type: Rx VIDEO/AUDIO INTERFACE Connector Type: 1x Type A 19 Pin, female Signal Type: HDMI 1.3C Video Codec: H.264 Decoding Max Input Resolution: 1080P @ 60fps Max Latency: 0.5 Seconds ETHERNET INTERFACE Connector Type: 1x RJ45 Cable Type: Straight through or cross over Cat.5E cable or higher, Auto MDI/MDIX Rate: 10/100Mbps for full duplex IR CONTROL INTERFACE Connector Type: 3.5mm Jack Frequency: 30K to 60K (Universal Frequency Band) RS232 CONTROL INTERFACE Connector Type: 3P PH: 3.81mm Terminal Block Baud Rate: 2400 to 115200 bps, manual set using 3-bit DIP-SW GROUP SETTING DIP Switch: Up to 16 group manual setting by 4-bit DIP-SW INDICATORS Red LED: PW On / IR: Power On and Remote active Green LED: LINK: Network Data Link POWER Input Operating Voltage: DC 5v / 750mA Power Consumption: 3.75W MECHANICAL AND ENVIROMENTAL Weight: 435g Dimensions: 109 x 107.5 x 36mm Operating Temperature: -10°C ~ 60°C Humidity: 20% ~ 85% Storage Temperature: -25°C ~ 80°C Product ReviewsNo Reviews For This Product.Click to review this product
