SPRO 6MP IP Fixed Lens Turret With Microphone

Information:

• The DHIPD60/28RG-T-M is a grey 6MP IP Turret Camera with a built-in microphone and 50m IR distance. Also available in white.

• Model Number DHIPD60/28RG-T-M
• Image Sensor 1/2.9” 6 Megapixel progressive scan CMOS
• Effective Pixels 3072(H) X 2048(V)
• Scanning System Progressive
• Electronic Shutter Speed Auto/Manual, 1/3(4)~ 1/100000s
• Min. Illumination 0.04Lux/ F1.6 ( Color, 1/3s, 30IRE), 0.4Lux/ F1.6
• ( Color, 1/30s, 30IRE) 0Lux/ F1.6 (IR on)
• S/N Ratio More than 50dB
• Max. IR LEDs Length Distance up to 50m
• IR On/Off Control Auto/ Manual
• IR LEDs 1
• 3 Year Warranty

• Lens Type Fixed lens
• Mount Type Board-in
• Focal Length 2.8mm
• Max. Aperture F1.6
• Focus Control Fixed
• Angle of View H:98°, V:67°

• Pan/Tilt/Rotation Pan: 0° ~ 360°/Tilt: 0° ~ 78° /Rotation: 0° ~ 360°

• IVS Tripwire, Intrusion, Object Abandoned/ Missing
• Advanced Intelligent
• Functions Face Detection

• Compression H.265+/ H.265/ H.264+/ H.264
• Streaming Capability 3 Streams
• Resolution (3072×2048)/ (3072×1728)/ (2592×1944)/ (2688×1520)/ (2560×1440)/ (2304×1296)/
• 1080P(1920×1080)/ SXGA (1280×1024)/ 1.3M (1280× 960)/ 720P (1280×720)/
• D1 (704×576/ 704×480)/ CIF (352×288/ 352×240)
• Frame Rate-Main Stream 6MP (1~20fps), 4MP (1~25fps) ;
• Frame Rate-Sub Stream D1 (1 ~ 25fps)
• Frame Rate-Third Stream 1080P (1~25fps)
• Bit Rate Control CBR/VBR
• Bit Rate H.265: 14K ~ 9984Kbps / H.264: 24K ~ 10240Kbps
• Day/Night Auto(ICR) / Color / B/W
• BLC Mode BLC / HLC / WDR (120dB)
• White Balance Auto/ Natural/ Street Lamp/ Outdoor/ Manual
• Gain Control Auto/Manual
• Noise Reduction 3D DNR
• Motion Detection Off / On (4 Zone, Rectangle)
• Region of Interest Off / On (4 Zone)
• Digital Zoom 16x°
• Flip 0°/90°/180°/270°
• Mirror Off / On
• Privacy Masking Off / On (4 Area, Rectangle)

• Compression G.711a/ G.711Mu/ AAC/ G.726

• Ethernet RJ-45 (10/100Base-T)
• Protocol HTTP; HTTPs; TCP; ARP; RTSP; RTP; UDP; SMTP; FTP; DHCP; DNS; DDNS;
• PPPOE; IPv4/v6; QoS; UPnP;NTP; Bonjour; 802.1x; Multicast; ICMP; IGMP; SNMP
• Interoperability ONVIF, PSIA, CGI
• Streaming Method Unicast / Multicast
• Max. User Accessr 10 Users
• Edge Storage Local PC for instant recording
• Web Viewer IE, Chrome, Firefox, Safari
• Management Software SPRO CSS
• Smart Phone iPhone,iPad & Android

• Audio Interface Built-in Mic (Directional)

• Power Supply DC12V, PoE (802.3af) (Class 0)
• Power Consumption < 6.0W
• Working Environment -30ºC ~ 60ºC / Less than 90% RH
• Ingress Protection IP67
• Casing Metal
• Dimensions 89.2 mm × Φ105.0 mm
• Weight 0.527Kg
