4 Inch Test Monitor - TVI - IP - Analogue

Product ID LCD390

Price: £349.99 (£419.99 Inc. VAT)

« Previous | Next »

Comprehensive All-In-One Analogue, HD-TVI & IP Professional CCTV Test Monitor

Analogue, HD-TVI & IP
BNC & RJ45 Sockets
Network Testing
12V DC Output & POE
Built-in LED Torch
ONVIF 2 Compatible
RS485 Testing
TVI Coaxitron
Full Qwerty Keyboard
8GB Storage For Recordings
The top of the range all-in-one tester LCD390 is capable of testing and configuring, Analogue, IP (ONVIF) and TVI equipment. It can also locate cable faults, test POE functions and much, much more.
Housed in a tough case with rubberised corner protectors it feels and looks as good as its high-end features. The LCD390 features a fold out Qwerty keyboard so that it’s easy to type in any alpha numeric characters when testing and configuring equipment.
If you are seeking a professional hand-held test meter the LCD390 will pay for its investment many times over giving you faster installation and fault finding due to its feature packed design.
BNC Ports - BNC ports for video in and out for testing Analogue and HD-TVI cameras. Test card display & Coaxitron control support.
ONVIF Testing - For setting up ONVIF IP Cameras.
Dual POE Ports - Single-line POE Testing. 1x Power-In Port & 1x Power-Out Port, Power POE Cameras, test voltage of POE ports and charge the test monitor!
Network Testing - Discover & Ping free network addresses.
Cable Breakpoint Testing - For testing the length and the point at which breaks occur in network cables.
TVI Coaxitron - Up the coax control of TVI cameras.
Shock Absorbing One Handed Design - Featuring drop-proof protective rubber corners.
Replaceable Battery - Easy to remove & replace Lithium-ion Battery with working time of 10 hours!
Record & Take Snapshots - Ideal for playback of camera tests!
Dual LED Lights - Super bright lights for instaing in dark spaces!
Multiple Connections - RS485, Audio In for testing microphones & Mini USB for connecting to a PC to download recordings and snapshots!
4" High Definition Screen - Crystal Clear images for testing video quality of cameras!
Full Qwerty Keyboard - Neatly folds away with a flip-open design!
You also receive all of these for free: Carry case with removable shoulder strap, Lanyard, BNC - BNC lead, 2.1mm DC power lead, RS485 test lead, USB - Mini USB lead, Audio test lead, Spare terminal block, 2x Phono - BNC converters, Power supply lead, POE power injector and a Network (patch0 lead
1 Year Warranty

Specifications

DC Range 12V DC
Power Charge Via POE (PSU Supplied)
Connections BNC, RJ45 & Mini USB
Storage Zipped Pouch
Sound Built-in Audio
Screen 4 Inch
Max Resolution Full 1080p HD
Video In Analogue, HD-TVI & IP
Video In Connection BNC & RJ45
Video Out Analogue & HD-TVI
Video Out Connection BNC
Battery Built-in Rechargable
Power Output 12V DC / 2A
Weight 1.6kg
Dimensions 190 x 113 x 37mm
