23x HD-TVI PTZ Camera with IR LEDs Grey

Product ID SEE-PTZ645LG

23x HD-TVI PTZ Camera with IR LEDs Grey

Price : £399.99 (£479.99 Inc. VAT)

FEATURES

720p Resolution
23x Optical Zoom
1.3 Mega Pixel Lens
200 Deg/Sec Pan Speed
75 Deg/Sec Tilt Speed
True Day/Night
12x IR LEDs
120m IR Range
Up The Coax Control
2 Alarm Inputs & 1 Alarm Inputs
Top of the range high speed PTZ with all the features needed for monitoring any large retail or commercial environment.
Capture quality 720p HD images with the 1.3 Mega Pixel Sony sensor. The PTZ module allows you to zoom right in while maintaining a HD image with its 23x optical zoom capabilities. There's also an analogue output for capturing 700TVL images on legacy systems.
The true day/night mechanical IR cut filter ensures the camera's sensor receives the optimum amount of IR light available day and night. The filter sits in place during the day preventing over saturation which results in colours being displayed incorrectly. At night the filter is removed so that the sensor receives as much light as possible creating the best quality image possible.
At night the PTZ's 12 IR LEDs provide an impressive 120m IR range so you wont miss a thing. The strength of the IRs automatically adjusts in-line with the optical zoom so that the image never appears bleached or under lit.
This high speed PTZ pans at up to 200 deg/sec and tilts at up to 75 deg/sec. The SEE-PTZ645's precision motor enables smooth movement even at maximum zoom. The PTZ also supports 360 degrees continuous rotation, 220 presets, 8 tours, 4 patterns and coaxitron or RS485 control. It also features 2 alarm inputs and 1 alarm output.
The sturdy camera casing is externally rate to IP66 and offers both lightning and surge protection and is available in both white or grey
Includes power supply and fixings
1 Year Warranty

SPECIFICATION

Image Sensor 1/3" Progressive Scan
Resolution 720p TVI / 700TVL Analogue
Lens Type 4-92mm 1.3 Mega Pixel
Image Output 1 Volt Peak-Peak 75 ohm
Min.Illumination 0 Lux with LEDs on
Day/Night Mechanical (True Day-Night)
InfraRed LEDs 12
IR Range 120m
Input Voltage 24V AC
Current Consumption 2.5A
IP Rating IP66
Iris Control Auto
Signal to Noise Ratio 50dB
Video Connection BNC Socket
Privacy Masking Yes
Digital Zoom Yes
Protocol Pelco D, P & Alien Coaxitron
Bracket Supplied
Finish Graphite Grey
Build Metal
Optical Zoom 23x
Pre-sets 220
Tours 8
Pan Speed 200 deg/sec
Tilt Speed 75 deg/sec
Alarm Inputs 2
Alarm Output 1
Alarm Connection Terminal Strip
Dimensions 240 x 368 x 360mm (Inc Bracket)
