We're really sorry... We don't currently have that one in stock Please add your email and we'll notify you when it's back Email Home» Accessories» Relay Boards Every Time TimerProduct ID AT-449Price: £39.99 (£47.99 Inc. VAT)+- Add to cart« Previous | Next »AT-449 A versatile unit with two timer periods Operate between 12V and 24V DC Adjustable from 1 second to 64 weeks Seven modes of operation Size: 100 x 55mm 3 Year Warranty SPECIFICATION Model Number: AT-449 Operating Voltage: 12 to 24v DC, maximum ripple 2V peak to peak Trigger Levels Low: Less than 220 ohms to ground OR an input of less than 0.8 volts Trigger Levels High: Greater than 4700 ohms to ground OR an input of greater than 4 volts Maximum input voltage 30V Minimum input voltage -4V Peak current available from either pin, 5mA AC Output Voltage: Maximum switching voltage 250 volts, maximum current 5 Amps (non inductive load) DC Output Voltage: Maximum switching voltage 30 volts, maximum current 5 Amps (non inductive load) Minimum switching level 5V @ 10mA Operating Temperature: -10°C~+60° Dimensions: 100x55mm Packing Weight: 86g Product ReviewsNo Reviews For This Product.Click to review this product
