Full HD CCTV system which performs exceptionally well in low light conditions
Suited to a wide range of CCTV applications, the Xvision Full HD Day/Night Dome cameras, provided as part of this system kit, excel in busy, low light conditions. Using their 2.1 MP 1080P Sony sensors, day and night recording is all carried out with ease, offering high quality monitoring for everything from shops, to bars, nightclubs, and hotels. 8 cameras are supplied in this package, all providing an extremely clear and detailed Full HD image which translates to over 3x more clarity than 720P digital CCTV cameras and over
6x that of analogue varieties. WDR DSP technology works in tandem with the high quality sensors to make these cameras a high performance choice.
High resolution output and wide viewing angles are further enhanced by the cameras’ IR sensitivity and realistic colour reproduction. These features ensure that all recordings provide clearly visible details, in all light conditions. The same image quality is experienced when streaming data from the cameras in Real Time, with H264 or MJPEG compression and dual streaming bandwidth management providing the processing economy necessary to drive the 1920x1080P resolution with ease.
The 8 Day/Night dome IP cameras are expertly constructed, with high quality housing finished in white offering solid protection to each unit. The cameras are packaged with all the software needed to install, view and control them, including Android/IOS apps and Windows CMS software.
The cameras feed into an NVR which features the same H264 video compression technology, allowing hard drive storage and bandwidth economy without compromising on a recording resolution which is capable of up to 5MP (2560x1920P) output. 30fps Real Time recording (with a 200Mbps bandwidth) is comfortably managed by this NVR and provides the same high resolution experience.
The backbone of a high quality NVR is a well manufactured hard drive and that is exactly what is found in the NVR included as part of this system kit. The highest standard of components are used to construct the hard drive, making it more than adequate to handle the 24/7 demands of a professional CCTV set up. The hard drive comes pre-installed in a choice of storage capacities, from 1TB to 12TB.
To install the NVR unit, a simple Plug and Play process is followed. All of the configuration controls, along with a LAN or Internet backup option, can then be easily accessed thanks to the comprehensive Windows and OSX CMS software package (included free). Backing up data becomes a simple procedure by taking advantage of the NVR’s USB connectivity. Various monitors can be connected to the unit via its additional VGA and Full HD 1080P HDMI simultaneous connectivity options. The recorder is even pre-calibrated to interact with Dropbox, providing a convenient cloud-based recording facility for motion activated events.
Additional features and specifications
The cameras:
• 3.6mm lenses with a 78° viewing angle capacity.
• True Day/Night (ICR).
• 0.0003 lux light sensitivity provided by a Digital Slow Shutter.
• A web based application for live viewing, setup and image controls.
• Privacy Masking feature, to mask areas of the cameras’ fields of view.
• A simple P2P setup procedure.
• High Speed Ethernet port (100MB) which is PoE compatible.
• Tamper resistant design with all parts inaccessible, such as cables and lenses.
• 3 Year Warranty.
The NVR:
• PoE switch built in.
• Multi Stream support, enabling minimised bandwidth and hard drive space usage.
• Intuitive local control due to the front panel keypad and USB Mouse.
• Features instant playback, search, backup and Auto Remote Setup (with QR code).
• Multiple levels of access to features can be established according to various user admin levels.
• Easy internet access setup (P2P, with no port forwarding necessary), along with internet browser viewing
and playback functions.
• Email alert function, using camera snapshots, activated when certain events are detected.
• All ports are high speed, with 100MB PoE IP camera ports and a 1GB Ethernet port.
• Smart Network Detection feature monitors interruptions to the network and identifies network problems.
• Alarm connectivity, with 1 alarm output and 8 alarm inputs.
• 3 Year Warranty
Please view the options above and select, as required, to ensure that you have all you need to install this CCTV system:
1. No cables required (I already have all necessary cables).
2. 25m Plug and Play Ethernet Cables for each included camera.
3. 1 x 305m cable roll with RJ45 connectors.
